Mesh Belt Annealing Furnace

The continuous annealing furnace is ideal for stainless steel tubes, copper-nickel alloys, and powder metallurgy, featuring a stainless steel chamber, PLC control, and precise PID temperature regulation.

  • CE/ISO Certification
  • Precise Temperature Control
  • Provide Customized Services
  • Safe and reliable

Introduction

Mesh belt annealing and protective atmosphere sintering furnaces are mainly used for sintering the inner and outer surfaces of stainless steel pipes, nickel alloy pipes, copper-based powders, iron-based powders, copper-nickel alloy pipes, etc. under a protective atmosphere. It is also suitable for batch Special small and medium-sized mechanical parts such as standard parts, bearings, chains, self-tapping screws, textile hardware, hand tools, elastic cushions, various textile needles, and sewing needles can be carburized, carbonitrided, quenched, etc. in a controlled atmosphere, heat treatment.

Mesh-belt-annealing-furnace-1

Features

  • The heating furnace is made of heat-resistant stainless steel, which has good structural strength, small thermal deformation, and long service life.
  • The mesh belt material is woven from imported heat-resistant steel wire.
  • The refractory material is made of all-fiber ultra-lightweight material for heat insulation, and the furnace has good heat preservation performance.
  • The transmission mechanism is simple and reliable, and the mesh belt speed is infinitely adjustable.
  • The temperature control system automatically completes the furnace temperature PID parameter setting, and the control is stable and reliable. It adopts double-meter temperature control according to the new international electrical standards.
  • The production line is equipped with a reliable mechanical transmission system, all automatically controlled by PLC programming, and equipped with fault self-diagnosis functions.

Technical Parameters

serial number

Furnace size

(length × width × height) ( mm )

rated power

( kW )

Rated temperature

( ℃ )

Belt running speed

( mm/min )

Belt width

( mm )

1

3000×350 ×150

60

1150

20~200

300

2

4000×450 ×150

90

1150

20~200

300

3

4000×550 ×180

100

1150

20~200

500

4

5000×650 ×200

120

1150

20~200

600

5

6000×650 ×200

150

1150

20~200

600

Applications

● Metal treatment

Mainly used for heat treatment of metal materials, such as improving the toughness of steel, copper, aluminum and other materials, reducing internal stress and improving performance.

● Plastic processing

Used to heat treat plastic plastics to change their physical properties and increase softness and ductility.

● Alloy production

Suitable for annealing of various alloys to adjust hardness and strength.

● Industrial production lines

Due to the continuous conveyor system, it is particularly suitable for industrial production lines that require efficient continuous production.

● Aerospace and Automotive Industry

Used to process various metal parts to meet high quality and performance requirements.
