Introduction
T-Bright lifting sintering furnace is specifically designed for sintering small-batch samples in laboratory settings. It is ideal for applications such as zirconia denture crystallization, structural ceramics, and polymer ceramics. The furnace boasts superior thermal insulation and high-temperature resistance, ensuring stable and consistent temperatures throughout the sintering process. An electric lifting platform allows for precise and efficient placement of the crucible, enhancing the overall ease of operation.
Features
1. T bright is specially designed for sintering small batch samples of zirconia denture crystal, structural ceramics and polymer ceramics.
2. The rated power is only 1kW, which is suitable for any small lab.
3. High-speed temperature increasing, 0-40℃/min.
4. 7-inch HD touch screen, Easy to operate, Can store 30 different processes, and programs.
5. 5pcs Mosi2 is heated in a ring shape, with higher furnace temperature uniformity.
Optional Spares
T-Bright Special sintering crucible
Standard Spares:
MoSi2 elements 2 pcs
Alumina crucible 1pcs
zirconia beads 1bag
Technical Parameters
Chamber size | 100*100mm (Dia*H) |
Max temperature | 1700℃ (<2 hour) |
Working temperature | 1600℃ |
Temperature control | 50 segments programmable and auto-control |
Thermocouple | B Type |
Temperature accuracy | +/-1 ℃ |
Power | 2 kW |
Net Weight | 75kgs |
Shape size | 420x570x825mm |
